Deciding between a table, a figure and text
Tables and figures are often the first parts of a paper an editor or reviewer looks at, and many readers never go further. Use a table when readers need exact values, such as baseline characteristics, regression coefficients or diagnostic accuracy estimates. Use a figure when the message is a pattern, trend or comparison: survival curves, forest plots, dose-response relationships or flow diagrams. If the point can be made in one or two sentences, keep it in the text. Avoid presenting the same data in both a table and a figure unless the journal asks for it.
Formatting tables that pass editorial checks
- Number and cite in order. Number tables consecutively with Arabic numerals and cite each in the text before it appears.
- Write a title that stands alone. State what, who, where and when, for example "Baseline characteristics of participants by treatment group".
- Use horizontal rules only. Most journals ask for three rules (above and below the column headings, and at the foot) and no vertical lines or shading.
- Put units in headings. Give units and summary statistics once, in the column or row heading, such as "Age, years, mean (SD)".
- Keep decimals consistent. Use the same number of decimal places for a variable throughout, and report P values according to the journal's style.
- Explain in footnotes. Define abbreviations and give statistical tests in footnotes, using the symbol order the journal specifies.
- Submit editable tables. Create tables with the word processor's table function, not as images or tab-separated text.
Preparing figures to journal specifications
Figure requirements are technical as well as editorial. Typical author instructions ask for line art at 600 to 1,200 dpi and photographs or halftones at 300 dpi or more at final printed size, in TIFF, EPS or high-quality PDF, with RGB or CMYK colour as specified. Size text so that it remains legible when the figure is reduced to column width, label axes with quantities and units, and keep fonts consistent across panels. Use colour palettes that remain distinguishable for readers with colour vision deficiency, and do not rely on colour alone to separate groups.
Image integrity matters too. Adjustments to brightness or contrast must apply to the whole image, and splicing of gels or blots must be indicated; journals increasingly screen for manipulation. Clinical photographs require patient consent and removal of identifying features, in line with ICMJE recommendations.
Legends, reporting guidelines and permissions
A figure legend should let readers interpret the figure without the text: describe what is shown, define symbols and error bars (standard deviation, standard error or confidence interval), and give the number of observations. Reporting guidelines specify some displays directly; CONSORT and PRISMA require flow diagrams, and STROBE asks for participant numbers at each stage. Figures reproduced or adapted from published work need permission from the copyright holder, and the source should be credited in the legend.
