Which template matches your study design

Each diagram on this page belongs to a reporting guideline from the EQUATOR Network family, and each one tracks a different unit through a study. Choosing the wrong template is a common reason for queries from editors, so start with the design rather than the diagram.

  • CONSORT 2025 (randomised trials): participants pass through enrolment, allocation, follow-up and analysis, with numbers randomised to each arm, losses, discontinuations and the numbers analysed.
  • PRISMA 2020 (systematic reviews): records move through identification, screening and inclusion, with separate columns for database and register searches and for other sources such as citation searching.
  • STARD 2015 (diagnostic accuracy studies): participants are followed from eligibility through the index test and the reference standard, so that missing or inconclusive results are visible for each test.
  • TRIPOD (prediction model studies): the diagram shows how the development and validation datasets were assembled, including exclusions and missing outcome data.
  • CARE (case reports): rather than counting participants, the case report diagram sets out the sequence of presentation, investigations, diagnosis, intervention and follow-up, which complements the timeline CARE asks authors to include.

Filling in the boxes without losing the reader

A flow diagram is only as good as the numbers inside it. Before you open a template, reconcile your counts from the source records: the screening log for a review, the randomisation list for a trial, or the enrolment register for a diagnostic study. Every box should sum to the box above it, and every exclusion box should give reasons with a count for each reason.

Typical problems that reviewers notice include totals that do not match the abstract or the first results table, exclusion reasons grouped as "other" with large counts, and a PRISMA diagram that reports records after de-duplication without stating how many duplicates were removed. For trials, the number analysed should be stated for each outcome where it differs, and the analysis population (intention-to-treat or per-protocol) should be clear from the diagram or its legend.

From planning to resubmission

These diagrams are useful well before the writing stage. Sketching the expected flow while drafting a protocol shows which data you will need to record, such as reasons for non-participation or the number of full texts that could not be retrieved. During data collection, updating the diagram as you go avoids a scramble to reconstruct numbers later.

At submission, most journals expect the diagram as an editable figure rather than a screenshot, and many ask for the completed checklist alongside it. In revision, reviewers often ask for a diagram to be split (for example, by trial arm or by data source) or for additional reasons to be itemised, so keep the underlying spreadsheet. Our notes on the CONSORT checklists, the STARD checklists and the PRISMA 2020 reporting checklist explain the items that sit alongside each diagram.

When you need more than a template

The PDFs above are starting points. Complex designs, such as cluster or crossover trials, reviews that combine new and previous searches, or diagnostic studies with several index tests, usually need an adapted layout. Guideline extensions exist for many of these designs, and their published diagrams should be followed where they apply. If you are preparing a review, our systematic review support includes building the PRISMA flow from your screening records, and case report authors can read more on the CARE guidelines.

Common questions

Can I edit these flow diagram templates for my own study?

Yes. The templates reflect the published diagrams of each guideline, and journals expect authors to adapt the box labels and add or remove boxes where the design requires it, for example extra arms in a trial or extra sources in a review. Keep the overall stages and the order of boxes recognisable, report reasons for every exclusion, and check that all numbers reconcile with your text and tables.

Does a case report need a flow diagram?

CARE does not require a participant flow diagram, because there is only one patient. It does recommend presenting the history of the case as a timeline. A simple diagram of presentation, work-up, diagnosis, treatment and follow-up can serve that purpose and helps readers follow the sequence of events, particularly when the clinical course was long or involved several interventions.
