Storyboard

Storyboarding a manuscript before drafting it

In scientific writing, a storyboard is a plan of a paper built around its key message and its figures before the prose is written. The method borrows from film: each panel of the board is one step in the argument. For a research article, the panels are usually the question and why it matters, the approach, each main result with the figure or table that shows it, and what the results change. Working this way shows early whether the data support a single clear message, whether a figure is missing, and whether some results belong in supplementary material or a separate paper.

Moving from panels to manuscript sections

  1. Write the one-sentence message. If it cannot be stated in a sentence, the paper may be trying to do two things.
  2. Order the figures. Arrange them so each one answers the question raised by the previous one. This order becomes the Results.
  3. Draft legends before text. A legend that stands alone forces you to decide what each figure shows.
  4. Write the Methods to match. Every result needs a method, and every method should produce a reported result.
  5. Write the Introduction and Discussion last. Frame the Introduction to lead to the question the figures answer, and the Discussion to interpret those figures, not new ones.

Check the board against the reporting guideline for your design at this stage; omissions are cheaper to fix in a plan than in a draft.

Storyboards for posters, slides and visual abstracts

Visual outputs need a storyboard even more than manuscripts, because space and attention are short. A conference poster is typically read from a distance in a short time, so the board should fix a reading path and a single headline finding. A video abstract needs a scene-by-scene script with timings and narration matched to visuals. A graphical abstract usually reduces the board to three or four panels: context, intervention or exposure, finding and implication. Slide decks for scientific talks follow the same logic, one point per slide in an order that builds.

Topics gathered on this page

The entries listed above range from journal communication, such as writing a withdrawal letter, to methods topics including meta-analysis techniques, the role of randomised controlled trials and literature reviews, and service areas such as case report writing, statistics, data collection and journal selection. Each can be used as a starting point for planning the corresponding document. The common thread is deciding what the reader must take away before deciding how to present it.

A practical way to test a storyboard is to show it to a colleague outside the project and ask them to state the main finding after a minute. If their answer differs from yours, the order or emphasis of the panels needs work before any drafting starts. This costs far less than discovering the same problem in peer review.
