Super-Resolved Imaging of Mouse Glomeruli via GloMAP
Graphical Abstract Sample Work
Understanding glomerular diseases is key for advancing kidney research. The Glomerulus Mapping and Analysis Pipeline (GloMAP) combines super-resolution imaging and 3D reconstruction to study whole mouse glomeruli at unprecedented resolution. This approach provides detailed insights into glomerular structure, aiding research into kidney disease and its pathophysiology
A methods paper presented as four process panels
This graphical abstract represents a methods study by Ali, Vaughan and colleagues, published in Kidney International in 2025, introducing GloMAP, the Glomerulus Mapping and Analysis Pipeline, for super-resolved optical imaging, three-dimensional reconstruction and spatial analysis of whole mouse glomeruli. Because the contribution is a technique rather than a single biological finding, the figure is built around workflow: four rounded panels take the reader from tissue preparation to imaging, reconstruction and one example of quantitative output. The intended audience is kidney researchers, pathologists and imaging scientists.
Why whole-glomerulus imaging at nanoscale is difficult
The glomerulus is the kidney's filtering unit, a tuft of capillaries surrounded by Bowman's capsule. Its filtration barrier involves specialised cells and basement membranes with features far smaller than conventional light microscopy can resolve. Electron microscopy provides that resolution but usually only in thin sections, which makes it laborious to reconstruct an entire glomerulus in three dimensions. Diseases such as focal segmental glomerulosclerosis (FSGS) involve changes in specific cell types and membranes, so whole-structure imaging that preserves cell identity is valuable.
Expansion microscopy offers one solution: tissue is embedded in a swellable hydrogel and physically enlarged, so that a conventional fluorescence microscope can resolve finer detail. GloMAP builds on this principle and adds segmentation and analysis steps tailored to the glomerulus.
Panels one and two: preparing and imaging the tissue
The "Stain and Expansion" panel shows five steps linked by arrows: a mouse kidney is harvested and sliced into 100 µm sections; the tissue is embedded in gel and denatured; it is fluorescently stained; and it is expanded in water. A grid overlay that grows with each step makes the physical enlargement immediately visible without numbers.
The "3D Imaging and Segmentation" panel shows the stains used: carbohydrate (green), amine/proteins (red) and nuclei (blue). A stack of optical sections is imaged in 3D to produce a fluorescent image of a glomerulus, which is then segmented into labelled compartments: mesangium, blood space, nuclei, Bowman's capsule basement membrane (BCBM), glomerular basement membrane (GBM) and Bowman's space. Scale bars of 20 µm appear on both images.
Placing the raw fluorescence image and its segmented counterpart next to each other, joined by an arrow labelled "Segment", shows exactly what the computational step adds. It also lets experienced readers judge whether the boundaries drawn by the pipeline match the anatomy they can see in the original image, which is the first question many reviewers ask of a new segmentation method.
Panels three and four: reconstructions and a quantitative readout
The "Mouse Glomerulus Reconstruction and Cell Types" panel displays rendered 3D objects in distinct colours. On the left of a dashed divider are structural compartments: BCBM, blood space, GBM, mesangium, Bowman's space and nuclei. On the right are cell types: glomerular endothelial cells (GEnCs), mesangial cells (MCs), podocytes and parietal epithelial cells (PECs). Separating structures from cell types helps the reader see that the pipeline identifies both.
The "Capsule Basement Membrane Thickness Distribution" panel shows three heat-mapped glomeruli labelled adult, aged and FSGS, with a colour scale from 0 to 2,000 nm. The aged and FSGS examples show visibly more areas at the thicker end of the scale. This panel demonstrates that the pipeline produces measurable spatial data that can be compared across conditions, which is the practical value of the method.
Visual choices that suit an imaging methods paper
- Real images alongside schematics. The schematic expansion steps are followed by genuine fluorescence and segmentation images, so readers see both the concept and the actual data quality.
- Consistent colour assignment. Each compartment keeps its colour across segmentation and reconstruction panels.
- Restrained conclusion. The conclusion describes GloMAP as a tool for nanoscale 3D imaging, reconstruction and analysis of whole mouse glomeruli across conditions, without claiming disease insights beyond what the example data show.
Images reused from the source are credited in a grey citation box, which is essential when microscopy panels are adapted from a published article.
Using the sample for a methods or imaging paper
Methods papers benefit from figures that let readers follow the protocol and then see an output metric. A four-panel workflow with a final quantitative example is a dependable template. Pubrica's graphical abstract service works with authors' own micrographs as well as illustrations, and scientific editing can help ensure that the methods text and figure use identical terminology for each compartment and cell type.
Questions about this sample
What does GloMAP stand for, and what does it do?
GloMAP is the Glomerulus Mapping and Analysis Pipeline. It combines tissue expansion, fluorescent staining, 3D super-resolved optical imaging, segmentation and reconstruction to map whole mouse glomeruli, identify their compartments and cell types, and measure features such as basement membrane thickness across different conditions.
Why does the expansion panel show a growing grid?
The grid overlay enlarges at each step to show that the tissue is physically expanded after being embedded in a gel and placed in water. This expansion is what allows a conventional fluorescence microscope to resolve structures that would otherwise be too small, and the grid communicates it without needing numbers.
What do the adult, aged and FSGS heat maps show?
They display the thickness of the Bowman's capsule basement membrane across the surface of a glomerulus on a colour scale from 0 to 2,000 nm. The aged and FSGS examples contain more areas at the thicker end of the scale, illustrating how the pipeline can compare structural features between conditions.
